Can Am Outlander 500/650/800/ Slip-On 06-12 Spring Performance Installation Instructions For Models: Outlander 800 (2006-2011), Outlander 500 (2007-2012), Outlander 650 (2006-2012)
1. Make sure the machine is on level ground and completely cooled down.
2. Loosen the Stock Springs that hold the Silencer and Head Pipe together.
3. Loosen the Silencer Mounting Bolts.
4. Brace the back of the Silencer with one hand, and take the bolts the rest of the way out.
5. Pull back and twist with until the Silencer is removed.
1. Slide the HMF Silencer over the Head Pipe.
2. Mount the Silencer with the supplied hardware. Do not tighten yet!
3. Install the Springs using a Spring Puller or a piece of wire and tighten the Mounting Bolts.
4. With most applications, tuning is a necessity.(See Figure #1)
